MaraniG

BWPS 300 - 2000.

Heat pump storage tank solar

300|2000lt

Application

This hot water storage tank features a double helix heating surface and solar exchanger, and is thus suitable for the combination of heat pumps with solar heating systems. It can also be used as a high performance storage tank for oil, gas, solid fuel and similar.

Corrosion protection for parts with drinking water contact

Enamelled as per DIN 4753. A magnesium anode offers additional corrosion protection.

External corrosion protection

Up to 600 l protective enamelled layers and foam encased 800 to 1,000 l powder-coated

Heat insulation

Type 300-600: 50 mm PU rigid foam insulation with soft sleeve
Type 800-1000: 95 mm PU rigid foam half-shell with soft sleeve
Type 1500-2000: 110 mm half-shell made of EPS with ABS sleeve
